48V 900Ah Lifepo 4 Lithium Battery Storage System

Product overview

BS-48900P-C Products are mainly for customized development of high power dc application backup power supply products, to provide emergency standby power. Battery system consists of 9 modules in parallel to form 48V900Ah system.

Product circuit principle
BS-48900P-C Product management system is made up of  9 independent unit BMS.
Unit BMS refers to the internal built-in 48V battery module, used for acquisition of monomer battery parameters, such as monomer voltage, total voltage, charge/discharge current, capacity, battery temperature, etc, used for battery charging and discharging process management, and effective protection and alarm function of the circuit system (protection and alarm functions), by collecting and protection circuit, electrical and communication interface and thermal management devices and so on.
48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System



Pic.2-1 48V900Ah battery system

48V900Ah battery system is composed of 9 sets 48V100AH battery in parallel, and the size of battery cabinet is 1200mm*600mm*1900mm.


Specification parameter

Serial numberItemTechnical parameters
           1Material systemLithium iron phosphate
           2Nominal voltage48V
           3Nominal capacity900Ah
           4Size1.2*0.6*1.9m
           5Weight550kg
           6Maximum charging current450A
           7Maximum discharge current450A
           8Operating environmentCharging 0ºC~+45ºC
Discharge-10ºC~+60ºC
          9Protection functionOver current protection, short circuit protection, over voltage protection, under-voltage protection, temperature protection
         10remote control functionRemote sensing, remote communication, remote control, remote regulating
         11Protection functionIP20 Protection grade
         12Communication interfaceRS232/RS485



48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System

Features of LiFePO4 battery
1.Longer Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar
    life than lead acid battery.helping to minimize replacement cost and reduce total cost of
    ownership.

2.Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in'
   replacement for lead acid batteries.Higher Power: Delivers twice power of lead acid battery ,
   even high discharge rate, while maintaining high energy capacity.

3.Wider Temperature Range: -20C-60C.

4.Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or
   combustion due to high impact,overcharging or short circuit situation.

5.Increased Flexibility: Modular Design enables deployment of up to four batteries in series
   and up to ten battery in parallel.



48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System
48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System

48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System

48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System


48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System
48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System
48V 900ah Battery Pack / Lithium Battery Pack for Solar System/Energy Storage System
