Rechargeable battery LiFePO4 battery 100ah 3.2V for telecom base deep cycle 3000 times

Rechargeable batteries Lifepo4 battery cell 100Ah 3.2v for Telecom base Deep Cycle 3000times Rechargeable batteries Lifepo4 battery cell 100Ah 3.2v for Telecom base Deep Cycle 3000times SPECIFICATION:DetailsParametersRemarksNominal voltage3.2VMean Operation VoltageRated capacityTypical100AhStandard discharge(0.2C)after

Featured Products

Rechargeable batteries Lifepo4 battery cell 100Ah 3.2v for Telecom base Deep Cycle 3000times

Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times
Rechargeable batteries Lifepo4 battery cell 100Ah 3.2v for Telecom base Deep Cycle 3000times

SPECIFICATION:
Details
Parameters
Remarks
Nominal voltage
3.2V
Mean Operation Voltage
Rated capacity
Typical
100Ah
Standard discharge(0.2C)
after standard charge
Minimum
 95Ah
Charge
Charge voltage
14.6±0.2V
Charge Moe
0.2C to 14.6V, then 14.6V to 0.02C (CC/CV)
Standard Charge current
20A
Max charge current
50A
Charge cut-off voltage
14.6±0.2V
Recommended float charge voltage ( for standby use)
13.8±0.1V
Discharge
Standard discharge current
20A
Max continuous discharge current
80A
Max. Pulse current
100A (<30min)
Discharge Cut-off voltage
8V
Cycle life
≥ 2000 cycles
0.2C 100% DOD
Operation Temperature
Range
Charge:0~45ºC
60±25%R.H. Bare Cell
Discharge:-20~60ºC
Storage Temperature
Range
0~35ºC
60±25%R.H. at the shipment state
Weight
Approx:12.2kg
Size
318 x 165 x 215mm
Plastic Case
ABS
Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times
Look here for more product series !

             Shenzhen  Deyee  Tech  Limited
Add: 16F International Business Bldg North,JiabinRoad,Luohu District,Shenzhen, China
Contact person: Nicole     Tel:86-755-88358613    Cell: (86)13537782427

ModelBattery MaterialNominal Voltage(V)Nominal Capacity (Ah)Internal Resistance (mΩ)Life CyclesMaximum Charge VoltageCut-off Discharge VoltageBattery weight (Approx.)Measurement(Φ*H)
DY-F14500LiFePO43.2V400mAh≤50≥20003.65V2.3V18.5g14×50mm
DY-F18500LiFePO43.2V1100mAh≤40≥20003.65V2.3V32g18×50mm
DY-F18650LiFePO43.2V1500mAh≤40≥20003.65V2.3V45g18×65mm
DY-F22650LiFePO43.2V2300mAh≤20≥20003.65V2.3V60g22×65mm
DY-F26650LiFePO43.2V3000mAh≤40≥20003.65V2.3V78g26×65mm
DY-F26650LiFePO43.2V3300mAh≤40≥20003.65V2.3V80g26×65mm
DY-F26650LiFePO43.2V3600mAh≤40≥20003.65V2.3V83g26×65mm
DY-F32650LiFePO43.2V5000mAh≤10≥20003.65V2.3V195g32*65mm
DY-F32650LiFePO43.2V5500mAh≤10≥20003.65V2.3V200g32*65mm
DY-F32650LiFePO43.2V6000mAh≤10≥20003.65V2.3V195g32*65mm
DY-F32700LiFePO43.2V6500mAh≤10≥20003.65V2.3V198g32*70mm
DY-F25LiFePO43.2V25Ah≤3≥30003.65V2.3V690g22*100*140mm
DY-F50ALiFePO43.2V50Ah≤1≥30003.65V2.3V1.2Kg39*148*95mm
DY-F50BLiFePO43.2V50Ah≤0.7≥30003.65V2.3V1.5Kg36*115*200mm
DY-F55LiFePO43.2V55Ah≤0.5≥30003.65V2.3V1.53Kg36*115*200mm
DY-F68LiFePO43.2V68Ah≤0.5≥30003.65V2.3V1.8Kg29.5*140*200mm
DY-F72LiFePO43.2V72Ah≤0.5≥30003.65V2.3V1.9Kg30*135*200mm
DY-F80ALiFePO43.2V80Ah≤0.5≥30003.65V2.3V2.0Kg29.5*135.2*220.5mm
DY-F80BLiFePO43.2V80Ah≤1.4≥30003.65V2.3V1.85Kg36*130*200mm
DY-F86LiFePO43.2V86Ah≤1≥30003.65V2.3V2.3Kg48*174*133mm
DY-F100ALiFePO43.2V100Ah≤0.5≥30003.65V2.3V3.5Kg67*142*215.5mm
DY-F100BLiFePO43.2V100Ah≤1≥30003.65V2.3V2.3Kg48*173*125mm
DY-F100CLiFePO43.2V100Ah≤0.6≥30003.65V2.3V2.25Kg40*130*220mm
DY-F176LiFePO43.2V176Ah≤0.5≥30003.65V2.3V4.5Kg71*180*279mm
DY-F180LiFePO43.2V180Ah≤0.5≥30003.65V2.3V6.0Kg71*182*279mm
DY-F200ALiFePO43.2V200Ah≤0.5≥30003.65V2.3V6.2Kg71*182*279mm
DY-F200BLiFePO43.2V200Ah≤0.5≥30003.65V2.3V4.2Kg54*175*207mm
DY-F202LiFePO43.2V202Ah≤0.4≥20003.65V2.3V4.0Kg54*173*209.6mm

Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times
Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times

Main Applications :

1.Energy Storage:
Solar-Wind Power System / City Grid (On/Off) / Community and Family / RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard / Vehecle.
2.Back-up System and UPS:Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment.
3.Other Applications:Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light / LED Backup / Engine Starting Battery,etc.

Company information:

Deyee are a Professional Manufacturer of LiFePO4, Lithium Ion, Li-Polymer, Ni-MH Battery Packs and Accessories.
After more than 10 years learning and exploration, we've grown to a company with complete R&D team and quality inspection system. We focus on battery solutions for Energy Storage System, Solar Street Lighting, Electric Vehicle, Telecom, Medical and UPS etc…

Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times
Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times

Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times
Quality assurance:

Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times
Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times


Payment & Shipping

Rechargeable Batteries LiFePO4 Battery Cell 100ah 3.2V for Telecom Base Deep Cycle 3000times

FAQ

Q1.Can you ship battery out of China?

R1:Yes,we can ship to any country out of China,you can tell us your address to check.


Q2.How do you ship the LiFePo4 battery packs?

R2:For sample order or small battery packs,we can ship by express through Fedex,UPS,TNT etc.If whole parcel over 100KG,can ship by air or by sea,sea shipping is more cheaper.
Customer can tell your nearest airport name and sea port name for us to check the best option for you.



Q3.Can we put different LiFePO4 battery pack in parallel or series by ourself?

R3:Yes. The battery can be put in parallel or series by customers. But there are few tips we need to pay attention:

1)Make sure the voltage of each battery are same before put inparallel. If they are not same, charge them to the same rate.

2)Don't not put discharged battery and  undischarged battery in parallel. This may reduce the capacity of the whole battery pack.

3)Advise us the target capacity of the whole pack if you would like to put them in series. We  will choose the suitable BMS for each battery.

4)If you are not professional in parallel and series batteries, please don't handle the battery by yourself. It may cause danger and hurt the cycle life of battery.


Q4.Can we put different LiFePO4 battery pack in series by ourself?

R4:You can buy big voltage directly from us.We suggest do not make them in series by yourself if you do not have experience,this will hurt the cycle life of the pack.


Q5.Does your battery pack include BMS?Can we use it for car?

R5:Yes,our battery pack include BMS,you can use it for low speed car only or aux. power for standard car.Do not use it for standard car directly,that will need more complex design BMS for the pack.


Q6.What is your warranty?

R6:We offer 12 months warranty for lithium ion battery pack and 2 years warranty for all our battery pack.we ensure at least 2000 cycle life for the LiFePO4 battery pack,which means,after 2000@80% DOD,there will still around 60% capacityt left.You can use it for at least 5 years for normal 1 time charge and discharge everyday.
